O Ring Gaskets by LSR Injection molding
High-efficiency 388-cavity LSR mold for silicone sealing ring production. Precision-engineered for cold runner injection molding with full machine
- Product Detail
Multi Cavity LSR Injection Mold for Silicone Sealing Rings
Machine Compatibility: Designed for LSR Injection Molding Machine Model L6068
Application: High-precision silicone gasket mass production
Model: TYM241422
Product Overview
This LSR injection mold is engineered for the mass production of silicone o ring with high output and exceptional consistency. With 388 cavities, it is optimized for full automation, suitable for applications that demand o ring tight sealing performance such as in household appliances, pressure cookers, automotive, and medical devices.
Technical Specifications
| Item | Description |
|---|---|
| Mold Model | TYM241422 |
| Mold Core Material | S136H (High-hardness stainless steel for extended mold life) |
| Mold Base Material | S50C (Standard mold base with strong structural performance) |
| Number of Cavities | 388 (Multi-cavity design for high-volume production) |
| Runner Type | Cold Runner |
| Cold Nozzles | 4-point cold nozzle system (including 1 with 97-style nozzle for precision control) |
| Matched Machine | TYM L6068 Horizontal LSR Injection Molding Machine |
